Eddy Current Separator

Request a Quote

Website: http://wastemachineltd.com/2-2-5-eddy-current-separator.html

Our eddy current separators, or non-ferrous separators are specialized machines that apply the principle of high-frequency magnetic field induction (eddy currents) to separate non-ferrous metals like aluminum and copper from waste mixtures.

The machinery applies powerful permanent magnets rotating at high speeds to generate a strong magnetic field. As a result, all metals that pass through this field become magnetized, causing them to be ejected from the conveyor.

Custom Options

Size

Motor configuration

Features

The separator is a highly effective piece of equipment that guarantees stable long-term performance even under demanding conditions. Non-ferrous metals are quickly and easily separated, allowing for superior recycling and waste management.

Application

Non-ferrous metal recycling

Disassembly and recycling industry of used household appliances

Recovery of non-ferrous metals from scrap materials of discarded household appliances

Automotive dismantling and recycling industry

Recovery of non-ferrous metals from automotive shredded materials

Recovery of non-ferrous metals from urban solid waste shredded materials

Recovery of non-ferrous metals from waste incineration ash and furnace slag

Recovery of recyclable non-ferrous metals from foundry sand

Recycling of waste aluminum electrolytic capacitors

Recovery of non-ferrous metals from waste steel slag materials

Technical Specifications

Model	TLFX (P)-8	TLFX (P)-10	TLFX (P)-12	TLFX (P)-14	TLFX (P)-16
Belt width (mm)	800	1000	1200	1400	1600
Belt legth (mm)	1500	1500	1500	1800	2000
Capacity (m3/h)	20	25	30	35	40
Length (mm)	4600	4600	4600	4900	5100
Width (mm)	2060	2260	2460	2660	2860
Height (mm)	1700	1700	1700	1700	1700
