Magnetic Separator
Request a Quote
Our magnetic separator is conveniently suspended 300–350 mm above the conveyor belt, allowing materials to pass smoothly underneath. It efficiently captures ferrous metals ranging from 0.002 to 2.5 kg mixed within non-magnetic materials. Featuring a self-cleaning permanent magnet design, this separator ensures reliable removal and high recovery rates of valuable magnetic metals like iron—helping you improve material purity and boost overall process efficiency.
Custom Options
- Size
- Motor configuration
Application
Magnetic separators are often applied in the sorting lines of operations in the following industries: MRF, MBT, cement, steel making, and mining. Separating ferrous metals from various waste mixtures allows operators to take these metals and recycle them as needed.
Advantages
- High Separation Efficiency
- Non-Magnetic Frame
- Roller Bearing Protection Device
- Wear-Proof Conveyor Belt Structure
- Easy to Maintain
Technical Specifications
| Magnetic separator type | Self-cleaning permanent magnet separator |
| Compliant conveyor belt width | 800mm, 1000mm, 1200mm (depending on actual needs) |
| Power | 4kW |
| Separator belt speed | 1.2m/s |
| Efficiency | ＞90% |
| Magnetic intensity | ≥700Gs |
| Working mode | Continuous or intermittent operation |
| Power supply | 380V/3phase/50Hz |
| Motor protection degree/insulation class | IP55/F |
| Frame material | Q235 |
| Magnet material | Composite material of NdFeB and strontium ferrite |
| Motor energy efficiency | Higher than level 2 of GB18613-2020 |
