Slitter Rewinder Machine, with Shaftless Mechanical Chuck, 300m/min, HCH3

Slitter Rewinder Machine, with Shaftless Mechanical Chuck, 300m/min, HCH3
Slitter Rewinder Machine, with Shaftless Mechanical Chuck, 300m/min, HCH3
Slitter Rewinder Machine, with Shaftless Mechanical Chuck, 300m/min, HCH3
Slitter Rewinder Machine, with Shaftless Mechanical Chuck, 300m/min, HCH3
Request a Quote

HCH3 slitter rewinder is typically constructed for converting jumbo rolls of high grade paper and self-adhesive paper/ films, delivering more productivity and higher load bearing capacity. This slitter rewinder machine is available in web widths of 1300mm, 1700mm and 2000mm, the machine speed is up to 300m/min.

Features
  • Individual shaftless unwinding;
  • Automatically push the finished rewind rolls;
  • Upper loading structure;
  • Double "S" structure
  • High-power servo motor;
  • Optional configurations of semi-auto blade set or full auto blade set;
Applications

Paper, self-adhesive paper/ film

Technical Data
Model HCH3-1300B HCH3-1700B HCH3-2000B
Unwinding width 1300mm 1700mm 2000mm
Machine speed 300m/min 300m/min 300m/min
Slitting accuracy ±0.03mm ±0.03mm ±0.03mm
Unwinding diameter φl200mm φl200mm φl200mm
Rewinding diameter 2*φ600mm 2*φ600mm 2*φ600mm
Main motor power 7.5kw 11kw 11kw
Rewinding motor power 2*7.5kw 2*11kw 2*11kw
Installation dimension 3980*4600*2250mm 3980*5000*2250mm 3980*5300*2250mm
Machine weight 6000kg 7000kg 9000kg
