500W Drive Motor Assembly (PMDC Brushless Motor) TF110BH2
Request a Quote
View All: http://motors-manufacturer.com/2-21-500w-drive-motor-assembly-pmdc-brushless-motor-tf110bh2.html
Your Motion
Application: electric material handling equipment
Technical Specifications
| Rated Power (W) | 500 |
| Rated Voltage(V) | 48 |
| No-load Current(A) | ≤3.0 |
| No-load Revolution (RPM) | 2750±8% |
| Rated Torque (N•m) | 1.98 |
| Rated Revolution (RPM) | 2400±8% |
| Rated Current(A) | ≤13.8 |
| Working Cycle (min.) | S2-60 |
| Insulation Class | F |
| Protection Level | IP44 |
| Gear Ratio | 28:1 |
| E-brake Voltage (V) | 48 |
| E-brake Torque(N•m) | 8 |
| Length (L/mm) | 277 |
Note: customized PMDC brushless drive motor assembly is available according to your application requirements and working conditions.
