Brushless DC Motor

Request a Quote

View All: http://motors-shanbo.com/2-brushless-dc-motor.html

Shanbo EM’s brushless DC motors are constructed using high grade rare-earth magnet and high quality ball bearing, offering greater flux density, higher efficiency, exceptional precision, faster speed, and lower noise level. These BLDC motors are typically suitable for applications where stable running and long lifespan are critical. When fitted with three Hall Effect sensors which are placed 120 degree apart from each other, or equipped with encoder, the brushless DC motor is applicable to precise positioning applications.

Motor Selection Range

Frame size: 30-180mm
Voltage: 7.2-230V
Speed: 100-50000rpm

Torque: 0.01-20N.m
Protection class: IP66
Operating temperature: -40°C – 120°C

Specifications

EM60ZWX11

Voltage: 12V DC
Torque: 39N.m
Speed: 65RPM

Power: 265W
Current: 55A
Working Duty: S2

Protection Class: IP54
Insulation Class: B

EM72ZWX02

Voltage: 28 DC
Torque: 0.35N.m
Speed: 11000RPM

Power: 400W
Current: ≤20A
Working Duty: S2-1min

Protection Class: IP2X
Insulation Class: B

EM72ZWX03

Voltage: 48 DC
Torque: 0.35N.m
Speed: 17000RPM

Power: 620W
Current: ≤18A
Working Duty: S2-1min

Protection Class: IP2X
Insulation Class: B

EM72ZWX04

Voltage: 48 DC
Torque: 0.19N.m
Speed: 20000RPM

Power: 400W
Current: ≤12A
Working Duty: S1

Protection Class: IP2X
Insulation Class: B

80BL04

Voltage: 12V DC
Torque: 1N.m
Speed: 3000r/min

Current: ＜2.5A
Working Duty: S1

Protection Class: IP54
Insulation Class: B

EM80ZWX20

Voltage: 24 DC
Torque: 2N.m
Speed: 3800RPM

Power: 800W
Current: 42A
Working Duty: S2

Protection Class: IP54
Insulation Class: B

EM80ZWX25

Voltage: 26 DC
Torque: 0.4N.m
Speed: 6000RPM

Power: 250W
Current: ≤12A
Working Duty: S2-60min

Protection Class: IP44
Insulation Class: B

EM80ZWX25A

Voltage: 13 DC
Torque: 0.4N.m
Speed: 6000RPM

Power: 250W
Current: ≤25A
Working Duty: S2-60min

Protection Class: IP44
Insulation Class: B

EM80ZWX26

Voltage: 48 DC
Torque: 0.6N.m
Speed: 3000RPM

Power: 200W
Current: ≤5.2A
Working Duty: S2-60min

Protection Class: IP44
Insulation Class: B

EM130ZWX52

Voltage: 48V DC
Torque: 3.2 N.m
Speed: 3000RPM

Power: 1000w
Current: < 25A
Working Duty: S2-10min

Protection Class: IP54
Insulation Class: B

Beside, Shanbo EM is able to offer custom made brushless DC motors per customer’s specific needs. We can do the job with results satisfying or beyond the expectations of our customers. Required parameters from customer are as follows:

Shaft
Installation sizes
Performance data

Protection class
Application environment

Lead wire
Connectors
