CMQ1680 Rotary Table Injection Molding Machine (for wide and flat mold)
Request a Quote
This product has been discontinued and removed from our shelves.
Technical Specifications of Rotary Table Injection Molding Machine Description | Unit | CMQ1680 | |||||
Injection Unit | Injection 1 | Injection 2 | |||||
Screw No | / | A | B | C | A | B | C |
Screw diameter | mm | 28 | 32 | 36 | 28 | 32 | 36 |
Screw length-diameter ratio | L/D | 24 | 21 | 18.7 | 24 | 21 | 18.7 |
Theoretical injection capacity | cm3 | 96 | 125 | 159 | 96 | 125 | 159 |
Injection weight(PS) | g | 87 | 114 | 145 | 87 | 114 | 145 |
Injection pressure | Mpa | 235 | 180 | 142 | 235 | 180 | 142 |
Screw rotational speed | rpm | 0~220 | 0~220 | ||||
Clamping Unit | |||||||
Clamping force | KN | 1680 | |||||
Moving mould distance | mm | 345 | |||||
Tie bar spacing | mm | 700×420 | |||||
Rotary diameter | mm | ¢760 | |||||
Max. mould thickness | mm | 430 | |||||
Min. mould thickness | mm | 150 | |||||
Ejector stroke | mm | 100 | |||||
Ejector force | KN | 33 | |||||
Ejector bar amount | PC | 2 | |||||
Distance between mould positioning centers | mm | 420 | |||||
Other Unit | |||||||
Max. pump pressure | MPa | 16 | |||||
Pump motor power | KW | 18.5 | |||||
Heating power | KW | 5.9+5.9 | |||||
External dimension(L×W×H) | mm | 5100×1700×1873 | |||||
Machine weight | kg | 8000 | |||||
Material cylinder capacity | Liter | 25+25 | |||||
Oil tank capacity | Liter | 305 |
As a specialized rotary table injection molding machine manufacturer, we also offer hydraulic two-platen plastic injection molding machine, sandwich co-injection molding machine, plate rubber vulcanizing machine, and rubber injection molding machine, etc. To keep and retain more customers, we are committed to offering high quality products at competitive prices. To illustrate, we ensure only qualified materials are used, and we also conduct rigorous quality controls on each manufacturing step. Due to our dedication to quality, our plastic injection molding machines are now CE certified. If you are in need of plastic injection molding machine, please contact us immediately. We look forward to working with you.
