Wheel Rim Vertical Wheel Rim Turning Lathe
Request a Quote
The wheel rim vertical wheel rim turning lathe is an upgraded lathe based on a prototype steel wheel rim vertical lathe. The body is manufactured with casting parts to enhance the overall support plate retraction function. In addition, a turning cutter adjustment device is designed to ensure turning operations of the steel wheel rim and tubeless steel wheel rim (ex-circle, inner-circle, and plane, outside and inside chamfer in single process) easier.
Parameters
| Spoke height | 30-160mm |
| Spoke diameter | Ф350-Ф600mm |
| Middle hole diameter | Ф140-Ф300mm |
| Production efficiency | 40-50Pcs/Hour |
| Main shaft speed | 125r/min |
| Mating power | 15kw |
| Machine overall dimension | 1860mm*1990mm*2150mm(L*W*H) |
| Total weight | 4T |
