Dropside Truck, FK6-80T

Dropside Truck, FK6-80T
Dropside Truck, FK6-80T
Dropside Truck, FK6-80T
Request a Quote
Basic Information
    1. Rated load
      8T
    1. Vehicle weight
      7.855T
    1. Front track
      1970mm
    1. Rear track
      1860mm
    1. Max. torque
      600N.m
    1. Max. output power
      118kW
Technical Specification
  • Drivetrain: 4×2
  • Wheelbase: 3800mm
  • Tonnage class: medium truck
  • Overall length: 7.08m
  • Overall width: 2.49m
  • Overall height: 3.15m
  • Front track: 1970mm
  • Rear track: 1860mm
  • Vehicle weight: 7.855T
  • Rated load: 8T
  • Total weight: 16T
  • Departure angle: 19°
  • Approach angle: 20°
  • Engine model: Yuchai
  • No. of cylinders: 4
  • Fuel type: diesel
  • Displacement: 4.26L
  • Max. output power:118kW
  • Max. horsepower: 160HP
  • Max. torque: 600N.m
  • Max. torque speed: 1300-1600rpm
  • Rated speed: 2600rpm
  • Truck bed length: 4.5m
  • Truck bed width: 2.3m
  • Truck bed height: 0.8m
  • Truck bed type: self-unloading
  • Gearbox model: FUKE
  • No. of forward gears: 10 gears
  • No. of reverse gears: 2 gears
  • Tire specifications: 10.00R20 18PR
  • No. of tires: 6
  • Fuel tank/gas tank capacity: 200 L
  • Frame height: 280(8 5)mm
  • Rear axle: 457/13T shortened bridge
  • Allowable load of rear axle: 10000kg
  • Speed ratio: 6.83
  • No. of springs: 8/10 8
