Man Lift for Truck Booth
Request a Quote
GZ Guangli’s paint booth man lift is a personnel access platform powered by compressed air without the use of any power supply. This man lift allows operator to easily reach the entire paint job by moving up and down, left and right, in and out, achieving three dimensional movement control. The work platform has guardrails at four sides with two gates to ensure the safety of operator. The control handle at platform enable operator to paint, mask, sand or other tasks on vehicles at appropriate height and position.
GZ Guangli’s paint booth man lifts can be applied to many large equipment such as buses, trucks, rail cars, aircraft, agricultural and construction equipment.
Specifications
- Model: GL1010
- Payload: 150kg (1 person)
- Recommended air pressure: 6-7bar
- Optimum air pressure: 6.5bar
- Air consumption: 350L/min
- Max. lifting height: 3100mm
- Platform extension: 900mm
- Cage dimensions (L×W×H): 900×720×1400mm
Upward moving
Downward moving
Front and back moving
Right and left moving
Click image to enlarge
