Multi Row Drilling Boring Machine
| Model | | | |
| Max. horizontal drilling dia. | Ø35mm (Single drill) | Ø35mm (Single drill) | Ø35mm (Single drill) |
| Ø13mm (Multi drill) | Ø13mm (Multi drill) | Ø13mm (Multi drill) | |
| Max. vertical drilling depth | 60mm | 60mm | 60mm |
| Boring bit dia. | 10mm | 10mm | 10mm |
| Max. working length | 2600mm | 2400mm | 2500mm |
| Min. working length | 130mm | 130mm | 130mm |
| Motor speed | 2840rpm/min | 2840rpm/min | 2840rpm/min |
| Quantity of drills | 21x3pcs | 21x4pcs | 21x6pcs |
| Motor power | 4.5kw | 6kw | 9kw |
| Overall dimension | 3600*2500*1550mm | 3600*2500*1550mm | 4300*3000*1550mm |
| Weight | 1260kg | 1400kg | 2200kg |
- Max. Horizontal drilling dia.: Ø35mm (Single drill), Ø13mm (Multi drill)
- Max. Vertical drilling depth: 60mm
- Boring bit dia.: 10mm
- Max. Working length: 2600mm
- Min. working length: 130mm
- Motor speed: 2840rpm/min
- Quantity of drills: 21x3pcs
- Motor power: 4.5kw
- Overall dimension: 3600*2500*1550mm
- Weight: 1260kg
- Max. Horizontal drilling dia.: Ø35mm (Single drill), Ø13mm (Multi drill)
- Max. Vertical drilling depth: 60mm
- Boring bit dia.: 10mm
- Max. Working length: 2400mm
- Min. working length: 130mm
- Motor speed 2840rpm/min
- Quantity of drills: 21x4pcs
- Motor power : 6kw
- Overall dimension: 3600*2500*1550mm
- Weight: 1400kg
- Max. Horizontal drilling dia.: Ø35mm (Single drill), Ø13mm (Multi drill)
- Max. Vertical drilling depth: 60mm
- Boring bit dia.: 10mm
- Max. Working length: 2500mm
- Min. working length: 130mm
- Motor speed: 2840rpm/min
- Quantity of drills: 21x6pcs
- Motor power : 9kw
- Overall dimension: 4300*3000*1550mm
- Weight: 2200kg
This multi row drilling machine features multiple rows of drills, can greatly improve drilling efficiency. ANNT offers models of three rows, four rows and six rows for various applications of customers.
- Using well-known brand touch screen and PLC control system, significantly reducing failure rate;
- Large working range of drills, fast assembling of bits;
- The drilling depth and distance are controlled by photoelectric switch and linear guide, guaranteeing quick and accurate positioning;
- Using imported original electrical components and linear guide, providing high durability;
- High quality steel parts with high-strength heat treatment, efficiently preventing deformation;
- Equipped with digital calculator to measure sizes which enhances the work efficiency.
- The depth and distance of drill hole will be accurately shown on high-precision digital display;
-
-
World’s well-known brand spindle motor and imported drills, ensuring precise and stable drilling performance;
-
-
Utilizing well-known brand touch screen and PCL control system, providing easy operation while reducing failure rate;
-
-
Stable electrical circuit and wiring, enabling the operation more safe;
-
-
Imported linear guide, ensuring high accuracy;
-
-
Lubrication system prolongs the service life of the machine;
-
-
Cable guide chain protects cables while facilitating cable movement;
-
-
Fixing the position of drills, preventing inaccurate drilling position caused by the misalignment of drill row;
-
-
The depth and distance of drilling are controlled by photoelectric switch, guaranteeing quick and accurate positioning;
-
-
Efficient filtration of water vapor in the air to prevent water vapor from entering air cylinder, prolonging the service life of pneumatic parts;
-
-
Positioning cylinder ensures high working stability;
