CHG400J Hydraulic Two-Platen Plastic Injection Molding Machine Manufacturer

CHG400J Hydraulic Two-Platen Plastic Injection Molding Machine

Request a Quote

View All: http://chap-machinery.com/2-4-8-plastic-injection-molding-machine.html

This product has been discontinued and removed from our shelves.

Features

As CHAP hydraulic two-platen plastic injection molding machine uses 45%-80% less energy than traditional injection molding equipment, it is energy saving and eco friendly.
The use of Siemens control panel which is specially designed for injection molding machine helps achieve real-time monitoring of the whole process and timely displaying of fault diagnosis.
Our two platen injection molding machine causes low noise during operation, thus helping create a comfortable environment.
The permanent magnet AC servo motor can reach the maximum output within 0.1 second.
Full closed-loop control.

Technical Specifications of Hydraulic Two-Platen Plastic Injection Molding Machine

Description	Unit	CHG400J
Injection Unit
Screw No	/	A	B	C
Screw diameter	mm	70	75	80
Screw length-diameter ratio	L/D	22.5	21	19.69
Theoretical injection capacity	cm³	1327	1523	1733
Injection weight(PS)	g	1208	1386	1577
Injection pressure	Mpa	207	180	158
Plasticizing capacity(PS)	g/s	44.9	51.4	58.7
Screw rotational speed	rpm	0~220
Clamping Unit
Mould clamping force	KN	4000
Moving mould distance	mm	1080
Tie bar spacing	mm	750×750
Mould clamping stroke	mm	1400
Min. mould thickness	mm	320
Ejector stroke	mm	200
Ejector force	KN	110
Ejector bar amount	PC	13
Other Unit
Max. pump pressure	MPa	25
Pump motor power	KW	37
Heating power	KW	21
External dimension(L×W×H)	mm	7.1×1.96×2.15
Machine weight	kg	45
Material cylinder capacity	Liter	50
Oil tank capacity	Liter	750

CHAP is a primary hydraulic two-platen plastic injection molding machine manufacturer based in China. We mainly produce vacuum rubber vulcanizing machine, rubber transfer molding machine, plate rubber vulcanizing machine and rotary table injection molding machine. Our products are EC and CQC certified, and they are well accepted by customers from Europe, South America, Southeast Asia, East Asia, Middle East, and other regions. In addition, our location in Ningbo City, provides us with easy access to convenient transportation, which reduces our transportation cost, enabling us to offer quality products at economical prices. If you are in need of our products, please contact us. Our staff is ready and waiting to serve you.
