Fiber Optic Loopbacks are designed to provide return patch for a fiber optic signal. They are widely applied in fiber optic testing applications or network restorations. When used for testing applications, loopback signals play a vital role in diagnosing problems. The best practice is to send a loopback test to network equipment, one at a time to avoid confusion.

Features
  • MPO, LC, SC or other customized types
  • Insertion loss <0.3dB
  • Attenuators are optional
  • Operating temperature from -20℃ to 70℃
  • Fiber types could be customize
  • In line with Telcordia, IEC, RoHS, REACH
Specifications
Type   LC/ SC/ MPO
Fiber Type / SM: G652D/G657A1 MM: OM1/OM2/OM3/OM4
Polishing Type / APC or PC
Housing Color / MM (Beige), OM3 (Aqua), OM4 (Purple ) SM APC (Green), SM UPC(Blue)
Insertion loss dB SC/LC< 0.3dB, MPO< 0.75dB
Return Loss dB SM>50dB; MM>30dB
Operating Temperature -40℃~85℃
