Gyratory Crusher
A gyratory crusher is used as a quartering hammer to extrude and crush materials, making it an ideal piece of equipment for the coarse crushing of ores and rocks in a variety of hardness rates. This equipment features a special lining board and crushing cavity structure, so that the crushed materials are cubic in shape, and the output of fine particles is significantly reduced. This equipment produces 625-2060t of finished products for hour, and because of this higher crushing capacity, the pressure of the belt conveyor transshipment point is reduced,（Reduce Motor Load）, which also reduces the cost of material processing and downtime. Thus the cost of material processing and downtime is reduced.
ApplicationGyratory crushers are used in crushing granite, basalt, diabase, andesite and other various hard rocks or ores.
According to the different feeding sizes, we have produced the following three crusher models:| Model | Feed opening size (mm) | Recommended maximum feeding size（mm) | Discharge opening size（mm) | Adjustment range of discharge opening （mm) | Production capacity (t/h) | Motor power（KW ) | Weight (t ) |
| PXZ0913 | 900 | 750 | 130 | 130-160 | 625-770 | 280 | 142 |
| PXZ1216 | 1200 | 1000 | 160 | 160-190 | 1250-1480 | 400 | 234 |
| PXZ1417 | 1400 | 1200 | 170 | 170-200 | 1750-2060 | 500 | 316 |
