Vertical Shaft Impact Crusher, VSI Crusher
Request a Quote
The vertical shaft impact crusher was developed to meet the needs of modern sand production. The maximum feeding particle size of this equipment is 45mm, the crushed products are cubic in shape, and the proportion of flat elongated particles is very low. This crusher is capable of simultaneously crushing 80 to 480t/hour, and producing 20-110t of sand, making it ideal for aggregate reshaping, artificial sand production and aggregate production in highway applications.
ApplicationThis crusher is widely used in the medium or fine crushing of various rocks, refractory matters, cement clinker, concrete aggregate and other hard or crisp materials.
Parameter| Model | Max feeding particle size（mm) | Range of rotor speed (r/min ) | Motor power (kw ) | Reshaping | Processing capacity (t/h ) | Sand production | Processing capacity (t/h ) |
| V6100 | 45 | 1390-2000 | 160 | 80-160 | 20-35 | ||
| V7100 | 1200-1580 | 132*2 | 160-240 | 35-55 | |||
| V8100 | 1200-1800 | 160*2 | 240-320 | 50-90 | |||
| V9100 | 1100-1600 | 240*2 | 320-400 | 60-95 | |||
| V9500 | 1100-1600 | 250*2 | 400-480 | 85-110 |
- Work noise is below 75db, which protects surroundings and the physical and psychological health of workers
- This equipment has a characteristic of little material moisture affection, so the water content of materials to be crushed can reach 8%.
