Low Voltage Power Factor Correction (PFC) Units

Low Voltage Power Factor Correction (PFC) Units
Request a Quote

Low voltage power factor correction units provide significant benefits to power systems, including an improvement in power quality, system capacity release, system loss reductions, electric utility bill reductions with no power factor correction. It also extends equipment service life by reducing unbalanced and impulsive loads. We offer customized low voltage power factor correction units to meet specific customer requirements. Please do not hesitate to contact us for more information.

Parameters
  • Rated isolation voltage: 660V, 1000V
  • Rated working voltage: 380V, 660V
  • Auxiliary circuit rated voltage: AC220V, 380V, DC110V, 220V
  • Rated frequency: 50Hz~(60)Hz
  • Rated current: horizontal bus≤3150A;vertical bus 630A, 800A, 1200A
  • Rated short-time withstand current: t50KA
  • Rated peak current: 50KA/0.1s
  • Short-circuit breaking capacity: 50kA(effective value)
  • IP grade: IP30, IP40
  • Bus configuration: three-phase four-wire, three-phase five-wire
  • Operating mode: Manual, Remote control, Auto
Normal Operating Conditions
  • Altitude: ≤ 2500m.
  • Ambient temperature: -5℃~+40℃
  • Relative humidity: ≤90%
  • Environments without risk of combustion, explosion, corrosion, dust, and vibration 5. Gradient: ≤ 5°, vertical installation.
  • If you can’t satisfy the above conditions, please contact us for a consultation.
