TFFN Copper Wire
Request a Quote
Thermoplastic Flexible Fixture Nylon (TFFN) wire has a PVC insulated conductor of soft bare or tinned copper wires and a nylon jacket with good oil resistance. PVC Nylon insulation has a smaller thickness than PVC insulation.
TFFN wire is to be used at 600 volts and at a max. conductor temperature of 90℃ in dry locations.
Applications:
TFFN copper wire is mainly used in electric appliances and machine tools.
Standards:
Our TFFN wire meets the requirements of UL 66.
Specifications:
| Conductor Size(AWG) | Conductor Stranding | PVC Insulation Thickness(mm) | Nylon Insulation Thickness(mm) | Nominal Diameter(mm) |
| 18 | 16/0.254 | 0.38 | 0.10 | 2.2 |
| 16 | 26/0.254 | 0.38 | 0.10 | 2.5 |
