Automatic Bottle Capping Machine

Automatic Bottle Capping Machine
Automatic Bottle Capping Machine
Request a Quote
LQ-XG

Screw capper for attaching screw caps on bottles and containers

  • Automatic bottle capping machines’ main function is to attach screw caps onto bottles and containers. Thanks to their innovative design and features, capping machines improve the capping process with its automated cap sorting, feeding, and capping functions, ensuring continuous and efficient operation. Ideal for use in various sectors, including cosmetics, food, beverages, medicine, biotechnology, health care, and personal care chemicals, as it can handle an array of bottles with screw caps.

    Furthermore, capping machines can be easily integrated with other production line equipment. It connects seamlessly with automatic filling machines via conveyors and can also link with electromagnetic sealing machines based on specific customer needs.

    Specifications
    Power Supply 220V, 50Hz, 850W, 1Ph
    Speed 20-40 pcs/min (depending on the bottle size)
    Bottle Diameter 25-120mm
    Bottle Height 100-300mm
    Cap Diameter 25-100mm
    Machine Size (L×W×H) 1200mm×800mm×1200mm
    Machine Weight 150
    *Air compressor is prepared by customer.
    *If the bottle and cap size are out of these range, please inform us. We can make the customized machine.
    Features
    • Equipped with a PLC for precise control, this machine features a touch screen interface with both Chinese and English options, making operations straightforward and easy to understand
    • Designed to ensure stable and reliable operation, the capping machine maintains consistent torque and is easy to adjust, even during extended periods of use
    • The bottle clamping belt is individually adjustable, allowing the screw capper to cap bottles of different heights and shapes effectively.
    • The entire capping machine can be quickly adjusted to accommodate different product sizes and cap types, enhancing its versatility and reducing downtime
    • Its compact design makes it easy to move and set up in different locations, adding to its operational convenience
    • Designed for easy use and simple adjustments, ensuring low maintenance costs and minimizing the need for extensive training
