87613 SAE 6000PSI Flange
Request a Quote
Application: for use with hydraulic braided hoses
Materials:- Stainless steel SAE 6000PSI flange
- Carbon steel SAE 6000PSI flange
| Part No. | Thread | Hose Bore | Dimensions | |||||
| E | DN | DASH | A | C | D | L | ||
| 87613-12-12 | 3/4" | 20 | 12 | 53 | 41.3 | 32 | 8.76 | |
| 87613-16-12 | 1" | 20 | 12 | 58 | 47.6 | 38 | 9.53 | |
| 87613-16-16 | 1" | 25 | 16 | 59.4 | 47.6 | 38 | 9.53 | |
| 87613-20-16 | 1.1/4" | 25 | 16 | 67.4 | 54 | 44 | 10.29 | |
| 87613-20-20 | 1.1/4" | 32 | 20 | 69.8 | 54 | 44 | 10.29 | |
| 87613-20-24 | 1.1/4" | 40 | 24 | 74.7 | 54 | 44 | 10.29 | |
| 87613-24-20 | 1.1/2" | 32 | 20 | 78.8 | 63.5 | 51 | 12.57 | |
| 87613-24-24 | 1.1/2" | 40 | 24 | 78.8 | 63.5 | 51 | 12.57 | |
| 87613-32-24 | 2" | 40 | 24 | 91.2 | 79.4 | 67 | 12.57 | |
| 87613-32-32 | 2" | 50 | 32 | 91 | 79.4 | 67 | 12.57 | |
