Carbon film resistor has advantages of wide resistance range and good stability, andit is uneasy to be affected by voltage and frequency. In addition, thisresistor is easier to manufacture, having low production cost. Thus, carbonfilm resistors are widely used in the DC and AC circuit of small electronicslike radio, television, calculator, video tape recorder, meters, etc.

Shapes and Dimensions

Type	Dimension (mm)
Type	L	D	H
RT-1MWS RT-1/6W	3.2±0.3	1.8±02	28±2
RT-1/2WS RT-1/4W	6.5±0.5	2.3±0.3	26±2
RT-1WS RT-1/2W	9.0±0.5	3.2±0.5	26±2
RT-2WS RT-1W	12±1.0	4.5±0.5	30±2
- RT-2W	16±1.0	5.0±0.5	28±2

Specifications

Power Rating		Maximum Working Voltage	Maximum Overload Voltage	Resistance Range +-5%
-	RT-1/6W	200	400	1-22M
RT-1/4WS	RT-1/4W	250	500	0.5-22M
RT-1/2WS	RT-1/2W	350	700	0.5-22M
RT-1WS	RT-1W	500	1000	0.5-22M
RT-2WS	RT-2W	500	1000	0.5-22M

Characteristic

Terminal Strength	No damage; △Rmax: ±0.3% or 0.5
Soldering Ability	Easy solderability; No damage; △Rmax: ±0.3% or 0.5
Temperature Resistance	△Rmax≤ ±0.5%
Vibration	No damage; △Rmax±0.5% or 0.5
Moisture Resistance	△Rmax: ±3%
Load Life	△Rmax: ±2.5%
Temperature Coefficient
Insulation Coefficient	2 x working Voltage; No beaakdown; △Rmax: ±0.5%
Insulation Strength	Min 10
Instantaneous Load	△Rmax: ±0.5%
Solvent Resistance	No damage

Derating Curve

Back in 1989, we began producing electronic components and now we own a complete line of manufacturing equipment and hold rich experience applied in the manufacturing of passive components. Shown above is one type of the thin film resistors with various models, and we have other types listed below.
