LED Transformers --Economic Type
Request a Quote
Features:
- 100~305VAC input range
- Metal case, IP67/IP65 design for indoor or outdoor installations
- Function options:
output adjustable via potentiometer; 3 in 1 dimming (0~10Vdc or 10V PWM signal or resistance, dim-to-off); smart timer dimming; DALI; auxiliary DC output (ELG-150 BE-Type) - Type "HL" LED drivers for use in Class I, Division 2 hazardous (Classified) location luminaries
- Suitable for LED street lighting and outdoor LED lighting
- 5 year warranty
Technical parameters:
| Model | Input voltage（V AC） | Current | Nominal voltage | Dimension（length*width*height mm） | Power |
| (mA) | (V DC) | (W/piece) | |||
| ELG-75-C | 100-240 | 0.35/0.5/0.7/1.05/1.4 | 107-214/ | 180*63*35.5 | 75W |
| 75-150/ | |||||
| 53-107/ | |||||
| 35-71/ | |||||
| 27-54 | |||||
| ELG-100-C | 100-240 | 0.35/0.5/0.7/1.05/1.4 | 143-286/ | 199*63*35.5 | 100W |
| 100-200/ | |||||
| 71-143/ | |||||
| 48-95/ | |||||
| 35-72 | |||||
| ELG-150-C | 100-240 | 0.5/0.7/1.05/1.4/1.75/2.1 | 150-300/ | 219*63*35.5 | 150W |
| 107-214/ | |||||
| 54-107/ | |||||
| 43-86/ | |||||
| 36-72 | |||||
| ELG-200-C | 100-240 | 0.7/1.05/1.4/1.75/2.1 | 142-286/ | 244*71*35.5 | 200W |
| 95-190/ | |||||
| 71-142/ | |||||
| 57-114/ | |||||
| 48-96 | |||||
| ELG-240-C | 100-240 | 0.7/1.05/1.4/1.75/2.1 | 172-343/ | 244*71*35.5 | 240W |
| 114-228/ | |||||
| 86-171/ | |||||
| 69-137/ | |||||
| 57-115 |
Dimension:
