Jack Stand, H405

Request a Quote

View All: http://pipe-weldingmachine.com/3-2-4-jack-stand.html

This pipe stand is specially designed for rolling and positioning of pipes with large diameter (max. 36 inches)
With a load capacity of 2500ld, its four rollers allows safe and fast pipe rotating, and saves the moving distance.
Large V head and heavy base make this pipe stand the most durable and functional one in the market.
Lockable casters are also optional for this stand, allowing the moving of pipes with diameter of 36 inches (no length limitation) in workshop and construction sites. In this way, no hoist or forklift is needed.

Technical Data

Model	H405
Pipe Diameter Loading Capacity	4” to 36”
Max Loading Weight Capacity with Rollers and Casters	2500lbs/1134kg
Max Loading Weight Capacity without Rollers and Casters	5000lbs/2268kg
Height adjustment range(mm)	28in. to 52in.
Weight(kg)	33kg

Features

2. Large size V head can support pipes with max diameter of 36 inches. Its supporting with steel material is more smooth and easy for rotation.
2. Lockable casters for easy positioning.
2. Adjustable height
