Automatic Cylindrical Hot Stamping Machine, JR-105T

Request a Quote

View All: http://packaging-printer.com/3-2-automatic-cylindrical-hot-stamping-machine.html

Hot foil stamping on round and cylindrical surfaces

Popular for its innovative five-station rotary design, the JR-105T hot stamping machine is widely used to print on round items with sizes that range between 7 and 35mm. This hot foil stamper has become a preferred choice in the automated printing equipment sector, known for its efficiency and precision.

Specifications

Printing Product Size (Diameter × Length): (7-35mm)×(15-120mm)
Maximum Printing Speed: 55pcs/min
Power Supply: 220V Single Phase 50HZ
Compressed Air Pressure: 4-6bar
Power Consumption: 5kW
Machine Dimensions (L×W×H): 1000×1000×1900mm
Weight: 700kg

Applications

Ideal for cosmetics and beverage packaging, this hot stamping machine decorates lipstick tubes, mascara bottles, and bottle caps, enhancing product aesthetics with elegant finishes.

Features

This cylindrical hot stamping machine has a five-station rotary design for efficient, with independently adjustable strokes for each station.

Equipped with servo-driven stamping heads for precise control and customizable settings.

Vacuum suction feature to ensure secure item placement and accuracy.

Equipped with smart features that prevent stamping if no item is detected and provide alerts for any loading or unloading issues, ensuring smooth operation.
