Shrink Sleeve Labeling Machine
Request a Quote
The shrink sleeve labeling machine is constructed with quality stainless steel and aluminum alloys for a strong, compact structure. Adjustment is easily controlled through a touchscreen, while the machine itself uses brand new design ideas and an advanced circuit design to reduce the need for mechanical adjustment and significantly increase label cutting precision and speed.
Features
- The shrink sleeve labeling machine utilizes an advanced and automatic human-computer interface control technology and high-quality electronic elements.
- Labeling machine operation and adjustment is easy, allowing it to be easily integrated into a production line.
- The cutter features a unique design that ensures the cutting wheel does not need to be changed. Simply change the blades as needed, and blade changeover is quick and easy.
- The unique press labeling method is convenient and easy.
- The complete machine driving structure allows for an easy bottle type change.
- The suitable shrink sleeve size is 5″～10″. The labeling machine will carry out a uniform, highly efficient stopping or feeding motion according to current application needs.
- The labeling machine is applicable for square or round bottles.
- It features a lift type central column with a freely adjustable height.
- An extremely sensitive fiber optic sensor is used to ensure an accurate cutting length.
Application
The shrink sleeve labeling machine is widely used for different bottle types, including beverage, household chemicals, cosmetics, cleaning products, agricultural chemicals, petroleum, and other products requiring shrink sleeve labels.
Applicable Bottle Types
Technical Parameters
| Machine model | TSB-250 |
| Main machine size | 2440×1000×2100 (mm) |
| Equipment size | 4500×1050×2200 (mm) (including heating tunnel shrinking machine) |
| Equipment weight | 550Kg |
| Productivity | 200bottles /minute (500ml PET bottle) |
| Suitable bottle (mouth) diameter | Φ50~Φ90mm |
| Wrap label length | 40 ~180 mm |
| Label thickness | 0.035 ~ 0.10mm |
| Volume label material | PVC, PET, OPP, OPS |
| Volume label shrinker | Steam type |
| Operation mode | Entirely automatic control |
