Epoxy Bushing
Interface A Bushing (250A)
250A epoxy bushing meets the requirement of EN50181 standard on the design of Type-A interface. It is made of epoxy resins with one end sealed within SF6 or high voltage insulating oil and the other end suitable for connection with European 250A elbow connector or European 250A straight connector. The bushing is applicable for connecting the cabinet body and 250A elbow connector or European 250A straight connector.
We provide various types of this product as below
Technical Data
| Voltage Class | 12kV | 24kV |
| Continuous Current | 250A | 250A |
| AC Withstand Voltage | 42kV for 1 min | 65kV for 1 min |
| Partial Discharge | 13.2kV, 10pC | 26.4kV, 10pC |
| Impulse Withstand Voltage (10 times for each polarity) | 75kV | 125kV |
Technical Data
| Voltage Class | 12kV |
| Continuous Current | 250A |
| AC Withstand Voltage | 42kV for 1 min |
| Partial Discharge | 13.2kV, 10pC |
| Impulse Withstand Voltage(10 times for each polarity) | 75kV |
Interface C Bushing (630A)
630A epoxy bushing fulfills the standard of EN50181 in design and is made of epoxy resins. One terminal is sealed within SF6 or high-voltage insulating oil and the other terminal can connect with the European T connector or insulating cap. It is applied in connecting the cabinet body and European T connector.
We offer various types of this product below
Technical Data
| Voltage Class | 12kV | 24kV |
| Continuous Current | 630A | 630A |
| AC Withstand Voltage | 42kV for 1 min | 65kV for 1 min |
| Partial Discharge | 13.2kV, 10pC | 26.4kV, 10pC |
| Impulse Withstand Voltage(10 times for each polarity) | 75kV | 125kV |
Technical Data
| Voltage Class | 12kV |
| Continuous Current | 630A |
| AC Withstand Voltage | 42kV for 1 min |
| Partial Discharge | 13.2kV, 10pC |
| Impulse Withstand Voltage(10 times for each polarity) | 75kV |
Technical Data
| Voltage Class | 12kV | 24kV |
| Continuous Current | 630A | 630A |
| AC Withstand Voltage | 42kV for 1 min | 65kV for 1 min |
| Partial Discharge | 13.2kV, 10pC | 26.4kV, 10pC |
| Impulse Withstand Voltage(10 times for each polarity) | 75kV | 125kV |
