  • The DT type rotary pre-made pouch filling machine is ideal for packaging solid products and supports a wide array of bag types, including paper bags and pre-made film laminated bags.
  • The filling machine reduces packaging material consumption and improves sealing property.
Features
  • This machine allows for a quick pouch changeover between different sizes, while the bag feeding system width is easily adjustable using the regulating handle.
  • Standard equipped pouch presence detection mechanism: if there is no bag or no bag opening, there is no filling. This avoids filling product and pouch wastage.
  • A frequency control device allows for free adjustment based on actual machine conditions.
  • Advanced PLC control with touch screen for easy and user-friendly operations.

Specifications
Model SK8-G200 SK8-G260 SK8-G300
Mechanical station Eight stations Eight stations Eight stations
Pouch type Self-supporting bags, handbags, 4-side sealed bag, 3-side sealed bag, paper bags and compound bag
Size of bag W:80-210mm L:100-400mm W:130-260mm L:100-400mm W180-300mm L:100-400mm
Package weight 10-2500g 10-2500g 10-2500g
packing speed 25-60bags/min (depending on the weight of product and filling weight) 25-50bags/min (depending on the weight of product and filling weight) 10-30bags/min (depending on the weight of product and filling weight)
Machine weight 1400kg 1500kg 1700kg
Voltage 380V three-phase 50HZ/60HZ
Total power 2.5KW 2.5kw 3.0kw
Air consumption 0.6m³/min(provided by the user) 0.6m³/min(provided by the user) 0.8m³/min(provided by the user)

If you are interested in Soonk's rotary pre-made pouch filling machine, please feel free to contact us!
