Rotary Pre-made Pouch Filling Machine, YT Type
Request a Quote
- The rotary pre-made pouch filling machine is used for the automatic dispensing and packaging of fruit juice, ketchup, seasoning sauce, chili sauce, hand sanitizer, detergent, edible oil and other liquids and sauce materials.
Features
- The rotary pre-made pouch machine is applicable to a wide range of bag types, including pre-made pouches laminated by films and paper bags. The high-quality pouch filling machine reduces bag and material loss and improves the sealing quality.
- A quick pouch changeover for pouches of different sizes and widths in the feeding system is easily adjustable using the regulating handle.
- Standard equipped pouch presence detection mechanism: no bag or no bag opening, no filling. This avoids filling product and pouch waste.
- A frequency control device allows for free adjustment according to actual factory conditions.
- Advanced PLC control with touch screen for easy and user-friendly operations.
Specifications
| Model | SK-G200Y6-YT | SK-G300Y8-YT |
| Pouch type | doypack, doypack with zipper, 3-side sealed bag, 4-side sealed bag, pouch, pillow bag, etc. | |
| Size of bag | W：80-200mm L:100-400mm | |
| Filling capacity | 5-1000g | |
| Packaging speed | 25-40 bags/min (depending on the weight of product and filling weight) | |
| Package accuracy | deviation≤±1 | |
| Total power | 380V,50Hz/60Hz,2.6kW | |
If you are interested in Soonk's rotary pre-made pouch filling machine, please feel free to contact us!
