Cold Shrink Breakout Boot
Request a Quote
- Material: silicone rubber
- Color: gray
Our cold shrink breakout boot is designed to provide ideal sealing and protection for cables. With its superior material and precise engineering, it guarantees reliable performance and convenient installation. Available in multiple specifications, including 3-core, 4-core, 5-core, and 6-core.
Size | Number of Cores | Body Diameter | Application Range (mm) | Finger Diameter | Application Range (mm) | Finger Length (mm) | Body Length (mm) |
WCSF 3-1(1#) | 2 | 80 | Ø46-Ø67 | 32 | Ø19-Ø26 | 45 | 130 |
WCSF 2-1(1#) | 80 | Ø34-Ø67 | 32 | Ø15-Ø25 | 35 | 120 | |
WCSF 3-(-1)(-1#) | 56 | Ø30-Ø43 | 20 | Ø10-Ø15 | 35 | 105 | |
WCSF 3-2(2#) | 47 | Ø23-Ø37 | 20 | Ø8-Ø15 | 35 | 100 | |
WCSF 2-2(2#) | 3 | 88 | Ø54-Ø78 | 35 | Ø21-Ø31 | 45 | 135 |
WCSF 3-(-2)(-2#) | 110 | Ø44-Ø95 | 47 | Ø20-Ø40 | 35 | 130 | |
WCSF 3-3(3#) | 65 | Ø36-Ø55 | 25 | Ø13-Ø20 | 35 | 125 | |
WCSF 2-3(3#) | 65 | Ø30-Ø55 | 25 | Ø10-Ø20 | 35 | 110 | |
WCSF 3-4(4#) | 104 | Ø62-Ø90 | 40 | Ø25-Ø33 | 45 | 150 | |
WCSF 2-4(4#) | 120 | Ø72-Ø105 | 47 | Ø31-Ø40 | 45 | 165 | |
WCSF 3-5(5#) | 140 | Ø88-Ø120 | 60 | Ø36-Ø52 | 55 | 180 | |
WCSF 3-5A1(6#) | 150 | Ø88-Ø128 | 65 | Ø36-Ø57 | 55 | 180 | |
WCSF 3-5A2(7#) | 165 | Ø88-Ø138 | 70 | Ø36-Ø62 | 55 | 180 | |
WCSF 4-1(1#) | 4 | 60 | Ø26-Ø25 | 20 | Ø10-Ø14 | 35 | 126 |
WCSF 4-2(2#) | 70 | Ø36-Ø55 | 25 | Ø12-Ø17 | 40 | 137 | |
WCSF 4-3(3#) | 88 | Ø51-Ø75 | 32 | Ø14-Ø25 | 40 | 145 | |
WCSF 4-4(4#) | 120 | Ø56-Ø92 | 47 | Ø19-Ø40 | 40 | 160 | |
WCSF 5-1(1#) | 5 | 70 | Ø36-Ø62 | 20 | Ø10-Ø14 | 40 | 123 |
WCSF 5-2(2#) | 88 | Ø46-Ø73 | 25 | Ø12-Ø17 | 40 | 134 | |
WCSF 5-3(3#) | 110 | Ø59-Ø95 | 35 | Ø16-Ø27 | 45 | 138 | |
WCSF 5-3A(4#) | 120 | Ø59-Ø100 | 40 | Ø16-Ø32 | 45 | 138 |
