Reel Handling Pallet Truck
Request a Quote
Reel handling pallet truck is frequently to handle rolls of material including paper, film, foil, textile and nonwovens. V-Pans are built to accommodate a customer’s roll sizes of 1200-2000 mm in diameter, weighing as much as 2T. It can prevent the cylindrical goods from rolling, which saves time and labor.
Features
- Electronic power steering function makes the operation easier.
- Humanized multiple-functional handle design makes it easy to operate.
- High quality hydraulic system has the features of low noise, low vibration and high sealing, it can guarantee stable speed of ascending and descending.
- Electronic limit switch can accurately control the maximum lifting height to prevent damaging motor.
- The hydraulic system with multiway valve can control the moving of left, right, forward and backward. The tilting speed of forward and backword can be adjusted.
- Equipped with the function of emergency reverse driving and emergency power off.
Technical parameters
| Model | QBA20Z | |
| Load capacity | Q(kg) | 2000 |
| Load center distance | c(mm) | 700 |
| Wheelbase | Y(mm) | 1450 |
| Service weight(with battery) | kg | 930 |
| Tyres | Polyurethane tyres | |
| Steer wheel size | Φ248×75 | |
| Load wheel size | Φ80×80 | |
| Caster Size | Φ115×50 | |
| Wheels quantity (x=drive wheels) | 1X+2/4 | |
| Tread, front | b10(mm) | 1040 |
| Tread, rear | b11(mm) | 391/526 |
| Max. lift height | h3(mm) | 100 |
| Fork height, lowered | h13(mm) | 170 |
| Overall length | l1(mm) | 2300 |
| Overall width | b1(mm) | 1200 |
| Fork dimensions | S/e/l(mm) | -- |
| Width over forks | b5(mm) | 1200 |
| Ground clearance, center of wheelbase | m2(mm) | 20 |
| Aisle width for pallets 1000*1200 crossways | Ast(mm) | 2830 |
| Aisle width for pallets 800*1200 lengthways | Ast(mm) | 2710 |
| Turning radius | Wa(mm) | 2020 |
| Travel speed, laden/unladen | Km/h | 6/6 |
| Lift speed, laden/unladen | m/s | 0.06/0.08 |
| Lowering speed, laden/unladen | m/s | 0.05/0.045 |
| Max. gradeability, laden/unladen | % | 5/8 |
| Service brake | Electromagnetism: regenerative brake | |
| Drive motor power | kW | 1.5 |
| Lift motor power | kW | 2 |
| Battery voltage/nominal capacity | V/Ah | 24/240 |
| Battery weight | Kg | 260 |
| Steering Type | Electronic | |
| Sound level at the driver's ear acc. to DIN12053 | dB(A) | 70 |
Headquartered in Ninghai, China’s hub of forklift trucks manufacturing, Cholift Forklift Co. is a trustworthy producer of reliable material handling equipment. Our warehouse equipment include electric forklifts, electric pallet jacks, pallet trucks, hand pallet jacks, and lift table carts. In addition to these outstanding products, we can also offer customers complete handling and industrial storage solutions according to their requirements.
