The optical filter mirror mount can be used in laser processing, optical experiments and automatic measurement and testing and other places that require to assemble filter mirror.

  1. WN01FL
  2. WN02FL
Specification
Model WN01FL
Mounting thickness 3 mm
Weight 0.05 kg
Features
  • The open structure makes it convenient to assemble and disassemble optical lens.
  • No contact design on both sides can protect the optical lens from scratching or bonding.
  • The mount is stable and safe with V - shaped support and locking knob.
Specification
Model WN02FL
A 25 mm 50 mm
B
5 mm
C 11 mm 30 mm
Mounting width 50 mm 50 mm
Mounting thickness 8 mm 30 mm
Weight 0.17 kg 0.2 kg
Features
  • The sliding mounting plate is continuously adjustable, suitable for holding lens with different thicknesses.
  • The elastic structure on the bottom of the sliding mouinting plate makes it move smoothly.
  • Use locking knob for stable holding.
