LED Work Light Bar
Description
The LED work light bar has a service lie of up to 3,000 hours. This work light bar is easier and faster to install over other light bars with the use of a screw on the bottom. This particular LED light is suitable for car modifications.
- L Series
- LM Series
| P/N | Dimension(mm) | LEDs | Watts | Amps/12VDC | Amps/24VDC | Lumens |
| | 252.2*138.2*78.4 | 12 | 36 | 2.25 | 1.13 | 2520 |
| 405.2*138.2*78.4 | 24 | 72 | 4.5 | 2.25 | 5040 | |
| | 609.2*138.2*78.4 | 40 | 120 | 7.5 | 3.75 | 8000 |
| | 864.2*138.2*78.4 | 60 | 180 | 10.5 | 5.25 | 12000 |
Operating Voltage: 10~30VDC
Operating Temperature: -40℃~65℃
Light Source: high light efficiency Cree LEDs
Light Color: pure white 6000K
Light Emitting Angle: 60° flood, 12° spot
Toughened glass aluminum die casting housing
Continuous Working Life: 30,000 hours
IP67
| P/N | Dimension(inch) | LEDs | Watts | Amps/12VDC | Amps/24VDC | Lumens |
| | 3.90 | 6 | 18 | 1.125A | 0.56A | 1260 |
| | 6.57 | 12 | 36 | 2.25A | 1.13A | 2520 |
| | 9.25 | 18 | 54 | 3.375A | 1.69A | 3780 |
| | 12.0 | 24 | 72 | 4.5A | 2.25A | 5040 |
| | 14.57 | 30 | 90 | 5.6A | 2.8A | 6250 |
| | 17.24 | 36 | 108 | 6.75A | 3.38A | 7560 |
| | 19.90 | 42 | 126 | 7.88A | 3.94A | 8820 |
Operating Voltage: 10~30VDC
Operating Temperature: -40℃~65℃
Light Source: high light efficiency CREE LEDs
Light Color: pure white 6500K
Light Emitting Angle: 40° flood, 15° spot
PC lens aluminum die casting housing
Continuous Working Life: 30,000 hours
IP67
Applications
LED work light bars are most often used in trucks, trailers, engineering vehicles, snowplows, forklifts, excavators and agricultural equipment.
