Needle Tine

Request a Quote

View All: http://lawnmowingparts.com/3-9-needle-tines-l-shaped.html

JDY’s tines are compatible with a variety of lawn aerator machines. Tines are produced by experienced engineers who are experts in understanding the requirements of lawn maintenance equipment performance.

With an excellent working effect and smooth inner and outer tine edges, the required mowing rate for lawn maintenance is easily met.

During lawn maintenance and punching processes, sand in the holes is unable to be completely removed, which often leads to local deformation of the lawn and bottom layer knots. JDY’s tines minimize the punching and actuality on the lawn, so that the sand volume removed is reduced, thus reducing customer operating costs.

Tine Specifications

JDY Needle Tines L Shaped
JDY PN.	Replace OEM PN.	Mount	Length	Tip O.D
JTCU15712	TCU15712	5mm	102mm	5mm
J100-3620	100-3620	5mm	163mm	5mm
JTCU15726	TCU15726	8mm	127mm	8mm
J100-3621	100-3621	8mm	187mm	8mm

Notes:

Tines can be customized according to your specific requirements.
