Automatic Stone Profiling Machine
The automatic stone profiling machine can process marble, granite, artificial stone and much more. The machine can cut stone in straight lines or arced lines. The size of finished workpieces can reach up to 3m x 1.3m.
Cutting effect| Appellation | Unit | SQ/PC-1300 | SQ/PC-1500 |
| Max. disc diameter | mm | Φ600 | Φ600 |
| Worktable size | mm | 3000×1300 | 3000×1300 |
| Cutter processing range | mm | 3000×1300×550 | 3000×1300×550 |
| Water consumption | m³/h | 6 | 6 |
| Power of main motor | kW | 15 | 15 |
| Total power | kW | 19 | 19 |
| Dimension (LxWxH) | mm | 5300×2300×2520 | 5300×2300×2520 |
| Weight | kg | 4300 | 4500 |
The profiling machine uses an optical fiber probe to track the lines of the model, and then automatically cuts the corresponding shape with diamond circular blade.
The blade speed can be adjusted with frequency converter when moving left and right according to the stone material. If equipped with rotational worktable, the machine can also process arc shaped stone.
The whole machine adopts microcomputer control system, or can be equipped with CNC system to avoid the trouble of making templates, making the machine has a higher degree of automation and higher cutting accuracy.
The whole machine is designed with two blades, with which it has a higher cutting efficiency, better stability and easier operation..
With special car-use paint, spray paint technology, multi-layer antirust and anticorrosion treatment applied, this kind of stone cutting machine has strong oxidation resistance.
Factory processing scene of a cooperated customer
