Fast Speed 3D/2D Engraving Laser Machine
Request a Quote
Model: GW-B06C
Features
- This fast speed 3D/2D engraving laser machine processes a variety of materials, including crystal, glass, acrylic, zircon, and other transparent materials. It will also engrave on metal, wood, plastic, and other non-transparent materials.
- The laser engraving machine can create 3D and 2D engravings for 3D crystal models, personalized crystal keepsakes, photo crystal blocks, 3D laser gifts, 3D laser engraved awards and trophies, and more.
- The open design allows the crystal engraving machine to process materials with a size much larger than the machine itself, thus improving the work flexibility.
- The laser engraver features a simple operation and easy maintenance.
- The fast speed laser engraving machine is designed with a high engraving speed, as well as a consistent and accurate laser point generation.
- The machine appearance and functions are customizable according to customer requirements.
Technical Parameters
| Model | GW-B06C |
| Laser pump | Diode pump laser |
| Laser power | 2W or 3W |
| Wavelength | 532 |
| Max. energy on one pulse | 1.2mj |
| Beam quality | M2< 1.5 |
| Laser frequency | Standard:3000HZ Optional: 4000HZ, 6000HZ |
| Q-switch | Acousto-optic Q-switch (AOQS) |
| Pulse width | 7ns |
| Max. engraving area | 1500mm*3000mm*100mm, 2000mm*3600mm*100m, or custom engraving area up to 4000mm*6000mm |
| Max. engraving speed | Standard: 3000 points/s Optional: 4000 points/s, 5800 points/s |
| Head of 3D laser machine | Single head |
| Power supply | 220V±10%/50Hz, 380V±10%/50Hz optional |
| Cooling | Air cooling |
| Laser resolution | 500-1200DPI |
| Focal distance | Standard:100mm Optional: 120mm, 165mm |
| Laser beam spot diameter | 0.02mm |
| Laser lifetime | 20000 h |
| Applicable materials | Engraving: transparent materials like acrylic, crystal, glass, zircon, PC/PET sheet, etc. Marking: non-transparent materials like plastic, wood, metal, organic minerals and more. |
| Working environment | Clean, dust-free and no vibration. It is recommended to work in an air-conditioned environment. |
| Operating temperature | 10-30°C |
| Dimensions | Machine dimensions vary according to the engraving area. |
| Motion | Five-axis linkage |
| Machine weight | 2000KG |
| Average power | 1000W |
| Warranty | One-year warranty, lifetime support service and optical components are not covered by the warranty. |
| Automatic file protection of power outage | Yes |
| Multi crystals engraving with one file | Yes |
Note: Standard 3D engraving laser machine model parameters are shown above. We also offer customized 3D laser engraving and marking solutions according to specific customer requirements.
