Single Drum Vibratory Roller GYD102
Request a Quote
- Hydraulic double drum drive, two-speed range and stepless speed change.
- Vibratory roller: Hydraulic double drum vibration, electronic controlled delayed starting of vibration, great exciting force with high compacting efficiency;
- Hydraulic steering, articulated frame with flexible operation.
Consulting Products Information
- Connective design for two anti-corrosive water tanks with large capacity, electronic control water spraying system, intermittent spraying.
- Hydraulic service brake, Electronic controlled parking brake, brake release device which can be applied for dragging the machine for short distance.
- Drive and vibration system are equipped with imported famous brand hydraulic components with reliable performance.
Technical Specification:
Model | GYD102 |
Length×Width×Height(mm) | 4350×1900×3050 |
Operating weight (Kg) | 10000 |
Drum width (mm) | 1700 |
Static linear pressure (N/cm) | 230 |
Vibration frequency (Hz) | 40/46 |
Centrifugal force(KN) | 110/65 |
Forward | 0~5.5/0~11 |
Reverse | 0~5.5/0~11 |
Diesel engine | Cummins 4BT3.9-C110 |
Rated output(KW) | 82 |
