25A-110A MTC MTK MTA MTX Thyristor Switching Module Manufacturer

25A-110A MTC MTK MTA MTX Thyristor Switching Module

Request a Quote

View All: http://electrical-relay.com/2018/4-1-4-25a-110a-thyristor-switching-module.html

The 25A-110A MTC MTK MTA MTX thyristor switching module is applied in the cutting process like the rectification, heating, speed governing, voltage stabilization, inverter, compensation, electroplate, electrolysis, spot welding and electric welding, and it also can be used in the devices like the charge-discharge device and soft start device.

Model specification

Technical parameters

Model		MTport25A	MTport55A	MTport70A	MTport90A	MTport110A
On state average current	A	25	55	70	90	110
Repetitive peak reverse voltage	V	400-2600
On stage peak voltage/current	V	1.9
On stage peak voltage/current	A	80	80	170	270	330
Repetitive forward-reverse peak current	mA	8	8	10	15	20
Trigger current	mA	100
Trigger voltage	V	2.5
Holding current	mA	100
Off state voltage critical rising rate	V/μs	800
On state current critical rising rate	A/μs	100
Maximum rated junction temperature	℃	125
Insulation voltage	V(AC)	2500

Dimension and installation style

① Dimension figure; ② Installation size; ③ Wiring diagram;
