Diesel Engine Powered Winch
Request a Quote
This diesel engine powered winch is mostly used in the line construction for erecting pylon and sagging operation.
Detailed Data
| Item Number | 09111 | 09112 | 09112D | |
| Model | JJC-30 | JJC-50 | JJC-50D | |
| Diesel Power (hp) | 4 | 6 | 7 | |
| Diesel Engine Model | Z170F | R175A | R180 | |
| Rotational Speed of Diesel Engine (rpm) | 2600 | 2600 | 2600 | |
| Traction Force (kN)/Pulling Speed (rpm) | Quick | 7/18.1 | 15/13.8 | 15/13.8 |
| Moderate | 15/7.2 | 30/5.7 | 30/5.7 | |
| Slow | 30/4.6 | 50/3.6 | 50/3.6 | |
| Reverse | -/5.2 | -/6.3 | -/4.1 | |
| Diameter of Drum Groove (mm) | Φ160 | Φ160 | Φ160 | |
| Overall Dimension (mm) | 800×620×520 | 890×670×520 | 890×670×520 | |
| Weight (kg) | 137 | 170 | 182 | |
