Load Former Palletizer
The semi-automatic load former palletizer is designed to integrate seamlessly with any flexo printer slotter die-cutter or cardboard box production line, enhancing operational efficiency and streamlining production processes. In addition to enhancing productivity, the system is designed to minimize operator fatigue.
By enabling all tasks to be performed at the same level, the load former system allows for the quick, safe, and hassle-free construction of stable and well-formed paperboard stacks, thereby increasing efficiency and reducing the risk of injury. The load former palletizer eliminates the need for operators to bend or lift heavy paperboard bundles, ensuring both efficiency and ergonomic safety.
- Dimensions (L*W*H): 5000*2650*1520mm
- Weight: 3500kg
- Total power: 35kW
- Stacked pallet size (L*W*H): 1900*1300*2350mm (max.), 1000*900*2350mm (min.)
- Max. pallet capacity: 900kg
- Stacking speed: 7.8 s/cycle
- Loaded pallet release speed: 18.5 s/cycle
(Other specifications can be customized based on customer requirements.)
Features- This former palletizer ensures high-speed, smooth, quiet operation with low failure rates, enhancing reliability and performance.
- The separator plates are made from aluminum, which makes them highly wear-resistant and low-friction. This prevents scratches on paperboard bundles, ensuring high quality output.
- The former load palletizer has a PLC control system that allows flexible adjustments to all settings and actions, ensuring adaptability to various operational needs.
- It is available in both right-hand and left-hand operation modes, catering to user preferences.
- Available with floor level load former palletizer and pit mounted load former palletizer.
