PJ Powder Liquid Mixer

Request a Quote

View All: http://dispersers-mixers.com/4-1-powder-liquid-mixers.html

Solid-liquid mixing system for low viscosity fluids with direct addition of lightweight powders

The uniquely designed mixing head of this powder liquid mixer combines jet technology with powder suction capabilities. It generates an axial flow that creates strong vertical convection in the container, while radial discharge vortices prevent air from being drawn into the system, allowing for rapid powder dispersion. The feed tube enables lightweight powders to be drawn directly from the material bag into the container, making this mixer suitable for powder-liquid mixing processes involving low-viscosity liquids.

Key Specifications

Rated power (kW) 2.2-22
Max. speed (rpm) 1470-2900
Powder suction rate (kg/min) 0-30
Max. processing capacity (L), H₂O 800-2500

Specifications

Model	Rated power (kW)	Max. speed (rpm)	Powder suction rate (kg/min)	Powder inlet size (inch)	Max. processing capacity (L), H₂O
PJ90	2.2	2900	0-4	/	50-70
PJ100	2.2	2900	0-6	/	50-150
PJ120	4	2900	0-8	1	100-400
PJ140	7.5	2900	0-12	1	200-1000
PJ160	11	2900	0-20	1.5	300-1400
PJ180	18.5	1470	0-26	1.5	500-1800
PJ200	22	1470	0-30	1.5	800-2500
