DM60 AC Drum Motor

Request a Quote

View All: http://zd-drivers.com/4-2-1-ac-drum-motor.html

Specifications

Rated Power W	Number of Stage	Gear Box Series	Gear Ratio	Max. Speed m/min	Rated Speed RPM	Rated Torque Nm	Traction N	Length mm
0.035	2	1	3.6500	129.107	684.9	0.40	14	350
			5.3600	87.918	466.4	0.60	21	350
			6.5500	71.945	381.7	0.80	25	350
			8.6300	54.605	289.7	1.00	33	350
		2	13.530	34.829	184.8	1.40	47	350
			18.920	24.907	132.1	2.00	66	350
			24.650	19.117	101.4	2.60	86	350
			28.050	16.800	89.10	2.90	97	350
			33.920	13.893	73.70	3.50	118	350
			44.690	10.545	55.90	4.70	155	350
			58.220	8.094	42.90	6.10	202	350
		3	67.080	7.025	37.30	6.30	210	350
			81.110	5.810	30.80	7.60	254	350
			91.360	5.158	27.40	8.60	286	350
			102.88	4.580	24.30	9.70	322	350
			118.98	3.961	21.00	11.2	372	350
			127.74	3.689	19.60	12.0	400	350
			145.36	3.242	17.20	13.6	455	350
			191.56	2.460	13.10	18.0	599	350
			231.61	2.035	10.80	21.7	725	350
