3-in-1 Multi-Function Plasma Cutter with TIG/MMA Welding
Request a Quote
CT 416
Features
- 3-in-1 multi-function machine, cost efficient and easy to operate;
- TIG welding: 180A, good weld seam formation and stable current;
- MMA welding: 160A, Ø3.2mm stick electrode, quick arc starting;
- Plasma cutting: 40A, suitable for cutting metals of 1-10mm in thickness;
- Compact size, lightweight, simple to install and easy to carry;
Specifications
| Model | | ||
| Power voltage (V) | 1P/AC220±15% | ||
| Frequency (Hz) | 50/60 | ||
| No-load loss (W) | 40 | ||
| Duty cycle (%) | 30% | ||
| Power factor | 0.73 | ||
| Efficiency | 80% | ||
| Insulation class | Class F | ||
| Protection grade | IP21 | ||
| Weight (kg) | 7.4 | ||
| Dimensions (mm) | 402×160×300 | ||
| Processing mode | Plasma cutting | TIG welding | MMA welding |
| Rated input current (I1max/A) | 30 | 24.1 | 32.9 |
| Max. effective input current (I1eff/A) | 16.4 | 13.2 | 18 |
| Output current range (A) | 20-40 | 10-180 | 10-160 |
| Rated Output Voltage (V) | 96 | 17.2 | 26.4 |
| No-load voltage (V) | 258 | 58 | 58 |
| Inter-diameter of burner (mm) | Ø 1.1 | - | - |
| Air compress (mPa) | 0.4 | - | - |
| Gas flow (L/min) | 80 | 2-5 | - |
| Cutting thickness | 0.3-16 | - | - |
| Arc striking | High frequency (HF) arc ignition | High frequency (HF) arc ignition | Contact arc ignition |
Package Included
- Air filter regulator, 1pc
- Ground clamp & cable assembly, 1 set
- TIG welding torch, 1pc
- Plasma cutting torch, 1pc
- Tungsten electrode, 1pc
- Quick connector, 1pc
- Gas hose, 1pc
- Allen key, 1pc
Optional Welding Accessories
Auto-darkening helmet
Welding gloves
Cutting torch shield cup
Plasma nozzle
Gouging nozzle
Plasma electrode
