Won-330(Hq-330) Servo Driven Slitter Rewinder, Automatic slitter rewinder
Request a Quote
The WON-330 label slitter rewinder for label finishing is easy to use and pre-set parameters for material and speed up to 300 m/min.
Features
1. Unwinder with closed-loop tension control. Electronic web guide with ultrasonic edge guide sensor. 76mm air expanding mandrel. Max unwinder diameter: 700mm.
2. Full servo system feeds, dispenses, and rewinds paper
3. Easy set up: preset parameters for the number of meters, labels, speed, and when to stop
4. Brush press unit allows the servo-driven slitter rewinder to easily rewind rolls
Parameters
| Item | S330 | S420 | S520 |
| Max Speed | 300 m/min | 300m/min | 300m/min |
| Max Web Width | 300 mm | 420 mm | 520 mm |
| Min Slit Width | 16 mm | 16 mm | 16 mm |
| Blades Installed | 6 Sets | 6 Sets | 6 Sets |
| Max Unwind Dia | cp 700 mm | cp 700 mm | cp 700 mm |
| Max Rewind Dia | cp 400 mm | cp 400 mm | cp 400 mm |
| Power Supply | 3 PH N PE | 3 PH N PE | 3 PH N PE |
| Air Supply | 0.4 ~ 0.6 M Pa | 0.4 ~ 0.6 M Pa | 0.4 ~ 0.6 M Pa |
| Weight | 1200 KGS | 1300 KGS | 1550 KGS |
| Overall | 1800*1200*1400mm | 1800*1290*1400mm | 2265*1390*1400mm |
| Main Power | 7 kW | 7 kW | 7 kW |
