Remote temperature controller transfers the related indoor temperature data to an on-off controller to control the valve, and thus, achieve temperature control. Moreover, the temperature controller communicates with the on-off controller every 10 minutes wirelessly (every 30 minutes for non-heating seasons), and can automatically regulate time correspondence to the on-off controller time.
Features- The wireless indoor temperature controller is able to automatically clean the valve with a one-button energy-saving mode.
- The remote temperature controller automatically inspects the signal intensity, facilitating the installation and usage.
- The circuit board features an ultra-low power consumption. In this case, the battery has a service life more than one heating season.
- This remote temperature controller has a low-voltage warning.
- The driver features a restoration feature, and the valve is open after cut-off. The driver is also equipped with an indicator to display the valve’s on/off and fault state.
| Operating temperature | -10～50℃ < 90%RH |
| Set temperature | 16～28℃ |
| Temperature control accuracy | ±0.5℃ |
| Temperature resolution | ±0.2℃ |
| Wireless transmit power | 5dBm; 10Bbm; 17dBm (adjustable three-gear) |
| Wireless receiving sensitivity | -115dBm |
| Wireless communication frequency | 470480Mhz |
| Wireless communication mode | Fsk |
| Max. Wireless sending current | 70mA |
| Max. Wireless receiving current | 15mA |
| Max. Wireless sleep current | 30uA |
| Operating voltage | DC3V (2 AAA battery) |
| Reliable transmission distance | Open area: 500m |
| Applicable medium | Water |
| Medium temperature | 0～90℃ |
| Protection class of drive | IP68 |
| Pipe type | Two-way, tee |
| Nominal diameter | DN20,DN25,DN32 |
| Working current | 100mA |
| Nominal pressure | 1.6Mpa |
| Connection mode | G3/4,G1,G1-1/4 |
| Power supply voltage difference | 24VDC |
| Communications | M-bus |
Outline size
