This product has been discontinued and removed from our shelves.

Vibration isolation optical table can be used in modern optical, physical mechanics, laser electron, optical communication test, instrument installation and other fields.

  1. WN01HB
  2. WN02HB
Parameter table of WN01VD vibration isolation optical tables
Model L-W-H Marks
WN01VD600x600x80 600-600-800 4 supports, M6 hole pitch 25mm
WN01VD750x750x80 750-750-800 4 supports, M6 hole pitch 25mm
WN01VD900x600x80 900-600-800 4 supports, M6 hole pitch 25mm
WN01VD1200x800x100 1200-800-800 4 supports, M6 hole pitch 25mm
WN01VD1500x1000x100 1500-1000-800 4 supports, M6 hole pitch 25mm
WN01VD1800x1200x150 1800-1200-800 4 supports, M6 hole pitch 25mm
WN01VD2000x1000x150 2000-1000-800 4 supports, M6 hole pitch 25mm
WN01VD2000x1200x150 2000-1200-800 4 supports, M6 hole pitch 25mm
WN01VD2000x1500x150 2000-1500-800 4 supports, M6 hole pitch 25mm
WN01VD2400x1200x200 2400-1200-800 4 supports, M6 hole pitch 25mm
WN01VD2400x1500x200 2400-1500-800 4 supports, M6 hole pitch 25mm
WN01VD3000x1000x300 3000-1000-800 6 supports, M6 hole pitch 50mm
WN01VD3000x1200x300 3000-1200-800 6 supports, M6 hole pitch 50mm
WN01VD3000x1500x300 3000-1500-800 6 supports, M6 hole pitch 50mm
WN01VD3500x1200x300 3500-1200-800 6 supports, M6 hole pitch 50mm
WN01VD3500x1500x300 3500-1500-800 6 supports, M6 hole pitch 50mm
WN01VD4000x1500x300 4000-1500-800 6 supports, M6 hole pitch 50mm
WN01VD4500x1500x300 4500-1500-800 6 supports, M6 hole pitch 50mm
WN01VD5000x1500x300 5000-1500-800 8 supports, M6 hole pitch 50mm
WN01VD6000x1500x300 6000-1500-800 8 supports, M6 hole pitch 50mm
WN01VD8000x1500x300 8000-1500-800 8 supports, M6 hole pitch 50mm
Features of WN01VD vibration isolation optical tables
  • The frame is made of high quality medium carbon steel plate with strong rigidity, small deformation and good welding performance.
  • Vibration can be controlled to the maximum extent by using honeycomb structure materials with low natural frequency and strong vibrate resistance.
  • Use high magnetic stainless steel plate, practical, beautiful and wear-resistant.
  • The vibration isolation support is made of composite material, stable and reliable, suitable for laboratory with good environmental vibration.
  • Wear-resisting screw and flat surface thrust ball bearing are used in the adjusting support, easy and reliable to use.
  • Flatness: < 0.05mm/m2
  • Roughness: 0.8μm~1.6μm
  • Natural frequency: 3Hz~6Hz
  • Amplitude: < 5μm
Parameter table of WN02VD vibration isolation optical tables
Model L-W-H Marks
WN02VD600x600x80 600-600-800 4 supports, M6 hole pitch 25mm
WN02VD750x750x80 750-750-800 4 supports, M6 hole pitch 25mm
WN02VD900x600x80 900-600-800 4 supports, M6 hole pitch 25mm
WN02VD1200x800x100 1200-800-800 4 supports, M6 hole pitch 25mm
WN02VD1500x1000x100 1500-1000-800 4 supports, M6 hole pitch 25mm
WN02VD1800x1200x150 1800-1200-800 4 supports, M6 hole pitch 25mm
WN02VD2000x1000x150 2000-1000-800 4 supports, M6 hole pitch 25mm
WN02VD2000x1200x150 2000-1200-800 4 supports, M6 hole pitch 25mm
WN02VD2000x1500x150 2000-1500-800 4 supports, M6 hole pitch 25mm
WN02VD2400x1200x200 2400-1200-800 4 supports, M6 hole pitch 25mm
WN02VD2400x1500x200 2400-1500-800 4 supports, M6 hole pitch 25mm
WN02VD3000x1000x300 3000-1000-800 6 supports, M6 hole pitch 50mm
WN02VD3000x1200x300 3000-1200-800 6 supports, M6 hole pitch 50mm
WN02VD3000x1500x300 3000-1500-800 6 supports, M6 hole pitch 50mm
WN02VD3500x1200x300 3500-1200-800 6 supports, M6 hole pitch 50mm
WN02VD3500x1500x300 3500-1500-800 6 supports, M6 hole pitch 50mm
WN02VD4000x1500x300 4000-1500-800 6 supports, M6 hole pitch 50mm
WN02VD4500x1500x300 4500-1500-800 6 supports, M6 hole pitch 50mm
WN02VD5000x1500x300 5000-1500-800 8 supports, M6 hole pitch 50mm
WN02VD6000x1500x300 6000-1500-800 8 supports, M6 hole pitch 50mm
WN02VD8000x1500x300 8000-1500-800 8 supports, M6 hole pitch 50mm
Features of WN02VD vibration isolation optical tables
  • The frame is made of high quality medium carbon steel plate with strong rigidity, small deformation and good welding performance.
  • Vibration can be controlled to the maximum extent by using honeycomb structure materials with low natural frequency and strong vibration resistance.
  • Use high magnetic stainless steel plate, practical, beautiful and wear-resistant.
  • Vibration isolation support uses two layer diaphragm capsule, which has good vibration isolation performance. Equipped with automatic inflation system. The structure is compact and stable.
  • The quiet air machine is used as the air source, low noise (< 65dB).
  • Wear-resisting screw and flat surface thrust ball bearing are used in the adjusting support, easy and reliable to use.
  • Flatness: < 0.05mm/m2
  • Roughness: < 0.8μm
  • Natural frequency: 1.2Hz~2.0Hz (vertical), 1.2Hz~2.0Hz (Horizontal)
  • Amplitude: < 1.2μm
  • Air pressure: 0.2-0.6 (Mpa)
