Calendar and Notebook Double Wire Binding Machine
Request a Quote
The calendar and notebook double wire binding machine adopts Siemens PLC and touch screen control, which is simple to operate. It accommodates wires from 1/4'' to 3/4'' and can complete the wire binding of 20 books per minute.
Technical Parameters
| Feeding Mode | Manual |
| Handling of Double Wire | Automatic cutting, insertion and closing |
| Wire Specifications | Diameter 1/4''-3/4'' Pitch 3:1 2:1 |
| Max. Paper Width | 520 mm |
| Max. Binding Width | 507 mm |
| Min. Paper Length | 75 mm |
| Working Speed | 1,200-1,500 times/hour |
| Size of Worktable (WXD) | 600 × 300 mm |
| Power supply | 220V/1P/50Hz |
| Air Compressor (not included) | 1.5 kW |
| Air Pressure | 6-8 |
| Machine Dimensions (W × D × H) | 1,030 × 770 × 1,200 mm |
| Net Weight (excl. power pack) | 220 kg |
| Dimension of Pay-off Unit (W × D × H) | 490 × 760 × 1,20020 mm |
| Weight of Pay-off Unit | 65 kg |
As a China-based calendar and notebook double wire binding machine manufacturer and supplier, XINWEI MACHINERY also offers hardcover pressing machine, automatic paper gluing machine, book packing machine, and book casing-in machine, among others.
