Benchtop Fume Hood

Request a Quote

View All: http://labfurnituremakers.com/6-1-benchtop-fume-hood.html

1. Model
2. TFG1500T
1. Standard
2. 1. Size:
    (L) 1500mm* (D) 850mm* (H) 2350mm
  2. Materials:
    The bench-mounted fume features a 1.2mm thick steel panel, the bench features a 1.0mm thick steel panel, epoxy powder coating; 6mm thick tempered glass vertical sash, and a PP material extract air collection duct.
  3. The extract air collection duct’s diameter is about φ200mm, and the connecting pipe’s height is 50mm. The LCD control panel controls the wind speed, power switches, lighting, fan, and indication light buttons.
  4. Includes one 30W fluorescent lamp, four water-resistant power sockets
  5. Color Finish: White
  6. Worktop: 19mm thick epoxy resin board
1. Description
2. The benchtop fume hood is used for the extraction of harmful fumes, aerosol, dust and heat from the internal workplace, protecting lab workers against hazardous substances and prevents dangerous fumes and other pollutants from entering the lab. It is NOT suitable for use with radioactive substances or microorganisms, as it is not explosion resistant and not suitable for openly breaking down chemicals.
1. Optional
2. 1. Fume Hood Length:
    1200mm or 1500mm or 1800mm
  2. Worktop Size:
    (L)1200mm/1500mm/1800mm * (D) 735mm
  3. Material:
    The fume hood body is made of stainless steel or PP panels
  4. Worktop Material:
    13/19mm thick HPL panel or 20mm thick industrial ceramic
  5. Customizable color
  6. The number of gas valves, water valves and power sockets is customizable
