Panelized Walk-in Temperature & Humidity Test Chamber
Environmental chamber designed with insulated panels for easy assembly and installation, and used for testing various products
Panelized walk-in chambers built with insulated panels offer a practical solution for creating large-scale testing environments. Their flexible structure allows easy installation and reconfiguration to match different facility layouts or evolving testing needs. With precise control of temperature and humidity, they help manufacturers verify product reliability under diverse environmental conditions.
- High-temperature testing
- Low-temperature exposure
- Constant temperature and humidity checks
- Alternating climate cycles
- Environmental stress screening
- 2 cable ports (Ø100 mm), supplied with grey soft rubber plugs and covers
- Hour meter
- Observation window (insulating glass with transparent heating film)
- 1 sample power control terminal
1 RS-485 communication port
1 RJ-45 Ethernet port - USB port
- Emergency stop
Mold growth testing function
Application: Enables mold growth and cultivation tests to simulate long-term exposure to humid environments.
Infrared radiation simulation
Application: Enables testing of how samples withstand prolonged infrared radiation, helping assess material durability under thermal stress.
- Customizable in size, temperature range, and ramp speed, with internal volumes available up to 2,000 m³
- Equipped with an electronic expansion valve to optimize cooling performance and reduce energy use
- Optional configurations tailored for industries such as photovoltaics, automotive, semiconductors, and new energy systems
| Model | | | | | | | | | | | | ||
| Chamber volume (m³) | 3.9/3.4 | 6.3/5.5 | 7.8/6.8 | 11.7/10.2 | 15.6/13.6 | 17.5/15.3 | 23.3/20.4 | 29.2/25.5 | 31.1/27.2 | 38.9/34.0 | 46.7/40.8 | ||
| Performance | Temperature range | -70℃~ 85℃ (customizable) | |||||||||||
| Humidity range (only models with humidity control) | (20~98)%RH/(20~75)℃ | ||||||||||||
| Temperature fluctuation | 0.6℃ | ||||||||||||
| Temperature deviation | ±2.0℃ | ||||||||||||
| Humidity deviation (only models with humidity control) | ±3.0%RH(>75%RH) ±5.0%RH(≤75%RH) | ||||||||||||
| Temperature rise rate | 25℃→ 85℃ | ||||||||||||
| ≤25min | ≤28min | ≤28min | ≤30min | ≤31min | ≤32min | ≤34min | ≤36min | ≤38min | ≤41min | ≤45min | |||
| Temperature drop rate | 25℃→rated extremely low temperature | ||||||||||||
| 30min-180min (depending on different models and configurations) | |||||||||||||
| Internal dimensions (mm) | W | 1800 | 2700 | 3600 | 2700 | 3600 | |||||||
| H | 2100 | ||||||||||||
| D | 900 | 1450 | 1800 | 1800 | 1800 | 2700 | 3600 | 4500 | 3600 | 4500 | 5400 | ||
Performance specifications are based on an ambient temperature between 15 °C and 35 °C, relative humidity up to 85%, and cooling water temperature not exceeding 28 °C. Measurements were taken with the chamber empty.
Certain models are compatible with standards such as PV1200/PV2005, PR303.5/PR308.2, and DBL5471/Fuvo. For details, please consult our technical team.
