Production Capacity: 8–25 bottles/min (adjustable); up to 1500 kg/h (industrial model)
Filling Weight: 1-3 kg per bottle (customizable)
Total Installed Power: ±12.5 kW
Rated Voltage: 220 V / 50 Hz (optional 380 V, 3-phase)
Total Line Length: ±11 m
Footprint (incl. operation space): ±80 m²
Total Line Weight: ±2.3 T

• Bottle Feeding and Material Handling: Bottle unscrambling system supports up to 60 bottles/min, combined with a 7,200 L/h Z-type elevator for smooth and stable material conveying.
• 14-Head Multihead Weigher: Provides high-precision weighing with an accuracy of ±1% and a speed of 10–30 bottles/min. All key components are made of SUS304 stainless steel, with Teflon sealing components for improved hygiene and sealing performance.
• Dual Filling System: Combines solid filling (popping boba) and liquid filling (syrup), with a liquid filling capacity of 500–1500 ml and a rotary filling system with hopper size of 50–180 mm. Equipped with a vibration function to minimize product breakage during filling.
• Post-Processing System:
  1. Film sealing (10–30 bottles/min)
  2. Capping (10–30 bottles/min)
  3. Single-side labeling (10–30 bottles/min)
  4. Metal detection system (Fe ≥ 0.6 mm, Non-Fe ≥ 1.0 mm, SUS304 ≥ 1.2 mm) to ensure product safety and regulatory compliance
• Food-Grade Design: Combines solid filling (popping boba) and liquid filling (syrup), with a liquid filling capacity of 500–1500 ml and a rotary filling system with hopper size of 50–180 mm. Equipped with a vibration function to minimize product breakage during filling.
• Flexible Configuration: Features adjustable speed, customizable bottle types, and seamless integration with existing production lines.

We provide a wide range of packaging solutions to meet different production scale and packaging format requirements:
