Boom Truck Crane, FK-100E

Boom Truck Crane, FK-100E
Boom Truck Crane, FK-100E
Boom Truck Crane, FK-100E
Request a Quote
Technical Specification
  • Rated lifting moment: 25mt
  • Rated lifting capacity: 10000kg (2.5m)
  • Max. outreach: 14.0m
  • Max. lines of hook: 6
  • Slewing angle: 360° (continuous)
  • Boom raising angle: 0-75°
  • Max. lifting height (from the ground when outriggers are fully extended): 16.1m
  • Length of boom (retracted): 5.3m
  • Length of boom (fully extended): 14.3m
  • Boom sections: 4
  • Outrigger span (fully extended): 5.6m
  • Rated flow rate: 60-90L/min
  • Operating pressure: 31Mpa
  • Rated oil tank capacity: 200L
  • Crane moment (dynamic): 416.0kN.m 42.4mt
  • Torsional moment (dynamic): 26.3kN.m 2.7mt
  • Crane weight: 3820/3850kg (Ground/High)
