GUIBAO 1077 Elastomeric Coatings

GUIBAO 1077 Elastomeric Coatings
Request a Quote

GUIBAO 1077 Elastomeric Coating is an elastomer anti-corrosion material specially formulated for the inner linings of coal-fired chimneys, sewage tanks, chemical treatment tanks, etc. The coating is acid/alkali and high temperature resistant, serving as a protective film of the inner lining of these components.

Features
  • Two-component, room temperature curing
  • Good flexibility, adapts to the stress caused by the expansion and contraction of different substrates. No cracking, no shedding
  • Strong corrosion-resistance to withstand the corrosion damage of high concentration acid and alkali materials at high temperatures
  • Excellent anti-permeability and abrasion resistance. Excellent resistance to abrasion and erosion caused by flue gas dust and the gas flow with high velocity
  • Outstanding resistance to temperature extremes. Can be used for a long time under 100℃ and can withstand short exposures to temperatures of 120℃-150 after curing
  • Great adhesion ability. Powerful adhesion to a wide range of substrates such as the concrete, steel substrate, FRP, etc
  • No harmful volatile gases, non-harmful to humans, non-polluting
Main Purposes
  • Anti-corrosion of the inner lining of the power plant chimneys, flue, cooling tower, etc.
  • Anti-corrosion of the inner lining of the concrete sewage tanks, steel tanks of the sewage disposal systems in sewage disposal plants, chemical plants, power plants, etc.
  • External anti-corrosion of the pipes, metal structural component, etc.

Specifications
Q/71304249-7.012-2014

Color
Part A of 1077 is in black, part B is in yellow, black paste after mixing.

Packing
Part A of 1077 is 20kg/plastic pail, Part B is in2.5L/metal pail (net 1.4kg);
Suggested mixing ratio (be weight) for part A&B is 14~16:1.

Serial number Performance Technical Specifications
1 Solid content ≥ 65%
2 Theoretical coverage area and thickness 4~6m2/kg, dry film 40~50μm
3 Tack free time, 23℃ ≤ 6h,140 ℃ ≤ 2h
4 Curing time, 23℃ 7d
5 Temperature resistance -40℃~200℃
6 Adhesive force (completely dry, square drawing method) Class 1
7 Salt spray and acid fog resistance/500h No bubbles, no shedding
8 artificial aging resistance /1000h No powder, no cracking, no shedding
9 Diluent amount 5%~15%
