Optical Coatings
ZCQ is a leading distributor of SOLIS products, including the Optical Coatings. To find out more how you can benefit by buying from ZCQ please contact us directly.
High Reflective Coatings (HR), Anti-Reflection Coating(AR), Protected Aluminum, Protected Gold
As a China optical fused quartz maker, we provide our customers with various optical coatings, including high reflective coating (HR), anti-reflection coating, protected aluminum, protected gold.
High Reflective Coatings (HR)
High reflection coatings (HR), made from gold, silver, aluminum etc., are a kind of thin film material mainly used for light or laser beam manipulation. Metallic high reflective coatings have very high reflection at specific wavelengths or designed spectral range at specific angle or angle range of incidence.
Anti-Reflection Coating (AR)
Anti-reflection coating (AR), a kind of optical thin film coating, is crucial component in optical systems with multiple lenses or other optics where the maximum possible light energy is needed. AR coatings (including SAR, VR, WAR and DAR) can reduce the intensity of ghost imagines produced in optical systems by multiple reflecting surfaces, and help produce brighter images.
| Work Wavelength Range | 200-1100nm |
| Wavelength Range of Passband | 360-600nm |
| Average Transmittance in Passband | ≥90% |
| Wavelength Range of Rejection Band | 200-350nm, 620-1100nm |
| Transmittance in Rejection Band | < 0.1%, for 200-350nm < 0.1%, for 620-1100nm |
- In order to avoid humidity & dust, optical product is encouraged to be stored indoors or in its original container.
- Keep the storage place dry and neat.
- Handle with care due to its brittle nature, to free the products from sweaty hands through wearing cotton gloves.
- Some optical glass could be cleaned through the mixture liquid made by industry alcohol, acetone or aether with lens tissue.
